| Đặc tính | Giá trị |
|---|---|
| Light Source: | Aiming pattern: single dot, 625nm LED Illumination: 630nm LEDs |
| Imager Field of View: | 46° Horizontal x 29.5° Vertical |
| Roll: | 360° |
| Pitch: | ± 65° |
| Yaw: | ± 60° |
| Print Contrast: | 25% minimum reflective difference |
| Swipe Speed (Vertical Read Rate): |
Up to 90 in./2.3 m per second |
| SGraphics Format Support: | Images can be exported as Bitmap, JPEG or TIFF |
| Image Transfer Speed: | USB 2.0: Up to 12 Megabits/second RS-232: Up to 115 kb/second |
| Image Transfer Time: | Typical USB application is ~0.2 seconds with a compressed JPEG of 100kb |
| mage Quality: | 120 PPI on a 4 x 6 in./10.2 x 15.2 cm document @ 4.7 in./11.9 cm |
| Interfaces Supported: | USB, RS-232, RS-485 (IBM 46xx Protocols), Keyboard Wedge |
| Symbology Decode: | 1-D, PDF417 (and variants), 2-D, Postal |
| Dimensions: | 5.512 in. H x 3.232 in. W x 3.150 in. D 14.0 cm H x 8.21 cm W x 8.0 cm D |
| Weight: | 9.5 oz./269 g |
| Color: | Midnight Black |
